7200/7400 Vigor Series Indicator

7200/7400 Vigor Series Indicator

  • Ideal for mobile applications such as forklifts, platforms, inside truck cabs, crane scales and OEM applications
  • The compact housing and versatile power supply makes it suitable for weighing through to OEM applications
  • Basic weight control or level control functions
  • Acrylonitrile Butadiene Styrene (ABS) housing construction
  • Long life rechargeable battery ideal for mobile installations
  • Magnetically coupled link on front fascia for easy access in situ for updates/setup of indicator
  • IP65 approved: dust tight and protection against projected water, increasing reliability and indicator life time
  • Wide DC operation (7-24V) to suit a variety of on-board OEM applications
  • Trade approved in Australia, Europe and USA
Models
  • Specifications

    • Materials: ABS housing
    • Display: LCD; 6 digits numeric
    • Setup and Calibration: Full digital with visual prompting
    • Digital Filter: Sliding window average from 0.1 to 4.0 seconds
    • Zero Range: Selectable from +/-2% to +/-100% full scale
    • Resolution: Up to 60K divisions, minimum of 0.25μV/division
    • Zero Cancellation: +/-2.0mV/V
    • Span Adjustment: 0.1mV/V to 3.0mV/V full scale
    • Excitation: 5V for up to 4x350 or 8x700 ohm load cells (4-wire or 6-wire plus shield)
    • A/d Type: 24bit Sigma Delta with 8,388,608 internal counts
    • Operating Environment:
      -Temp: -10 to +50°C ambient
      -Humidity: <90% non-condensing
    • Standard Power Input: 7 to 24VDC, 4.8, 9.6,12 and 24V batteries - ON/OFF key with memory feature
    • Variants:
      - AC Plug pack: 110/240VAC 50/60Hz in 12VDC 1.5A out
      - 12V battery pack (rechargeable NiMH)
      - 4 x AA batteries
    • Serial outputs:
      -RS-232 automatic transmit, network or printer outputs.
      -Transmission rate: 2400, 4800 or 9600 baud
    • Input/outputs: 2 outputs - isolated transistor drive outputs (300mA total at 50VDC)
    • Ratings:
      -IP65 rated housing,
      -4,000 d@0.8uV/d NMI (S-420), OIML R76
      -10,000d III/III L NTEP 08-072 A1
  • Options

    • Thermal Ticket Printer
    • Label Printer
    • Remote Display
    • Indicator Stand
